Floating Ball Valve, 300 LB, 6 Inch, ASME B16.5

Valmax > Valves > Ball Valves > Floating Ball Valve, 300 LB, 6 Inch, ASME B16.5

Short Description

Model No.: VM 13 BV 12 Clicks: 3051

China Ball Valve manufacturer Valmax supplies Floating Ball Valve, featured with 403 mm Face to Face dimension, API 6D, ISO 17292 (BS 5351) Valve standard.

Request a quote Share

Keywords: Ball Valves , API 6D Ball Valves .

Previous: Floating Ball Valve, 150 LB, 3/4 Inch, ASME B16.5
Next: Forging Ball Valve, 2500 LB, ASME B16.5, API 6D

Floating Ball Valve, 300 LB, 6 Inch, ASME B16.5 Key Specifications / Features

Body/Bonnet: ASTM A216 WCB.

Ball: ASTM A182 F316.

Seat: PTFE.

Stem: ASTM A182 F316.

Face to face dimension: 403 mm.

Valve standard: API 6D, ISO 17292 (BS 5351).

Flange standard: ASME B16.5.

Sealing pressure test: 57 BAR.

Shell pressure test: 78 BAR.

Floating Ball Valve, 300 LB, 6 Inch, ASME B16.5

Floating Ball Valve, 300 LB, 6 Inch, ASME B16.5 Key Specifications / Features
