Forging Ball Valve, 900 LB, 12 Inch, ASME B16.5, Devlon

Valmax > Valves > Ball Valves > Forging Ball Valve, 900 LB, 12 Inch, ASME B16.5, Devlon

Short Description

Model No.: VM 13 BV 17 Clicks: 3856

China Valve manufacturer Valmax supplies Forging Ball Valve, seat made of NYLON, featured with 965 mm Face to Face dimension, ASME B16.5 flange standard.

Request a quote Share

Keywords: Ball Valves , API 6D Ball Valves .

Previous: Forging Ball Valve, 900 LB, 8 Inch, ASME B16.5, PEEK
Next: Forging Ball Valve, 2500 LB, 16 Inch, ASME B16.5, PEEK

Forging Ball Valve, 900 LB, 12 Inch, ASME B16.5, Devlon Key Specifications / Features

Body/Bonnet: ASTM A105.
Ball: ASTM A105+ENP.
Seat: Devlon.
Stem: ASTM A105+ENP.
Face to face dimentision: 965 mm.
Valve standard: API 6D.
Flange standard: ASME/ANSI B16.5.
Sealing pressure test: 169 BAR.
Shell pressure test: 230 BAR.

Forging Ball Valve, 900 LB, 12 Inch, ASME B16.5, Devlon

Forging Ball Valve, 900 LB, 12 Inch, ASME B16.5, Devlon Key Specifications / Features
